- Tow/haul trailering mode w/control at center of shift lever
- All-wheel drive system-inc: automatic transfer case
- 3.42 rear axle ratio
- HD 600-CCA battery w/115 minutes reserve capacity
- 105-amp alternator
- Independent front torsion bar suspension
- Steel single-stage leaf spring rear suspension
- 6100# GVWR
- P215/75R15 all-season SBR tires
- Compact spare tire w/wheel mounted under floor
- 15" x 6.5" chrome wheels
- Variable assist pwr steering
- Pwr front disc/rear drum brakes
- 4-wheel anti-lock braking system (ABS)
- 27 gallon fuel tank
- Stainless steel muffler/tailpipe
- 6-wire trailering harness
- Roof-mounted black luggage carrier
- Body-color painted front bumper/rear bumper w/combination top step surface
- Molded grille w/chrome accents
- Halogen composite headlamps w/flash-to-pass, auto lamp control
- Lower bodyside cladding
- Black foldaway pwr mirrors
- Deep tint side/rear glass
- Swing-out windows on sliding door & left front quarter panel
- Intermittent windshield wipers
- Doors-inc: driver, front passenger, sliding RH side door
- Front license plate bracket
- 8-passenger seating-inc: (2) reclining high-back front bucket seats w/inboard armrests, map pockets, manual driver lumbar support, (2) removable 3-passenger bench seats
- Custom cloth seat trim
- Color-keyed floor carpeting
- Color-keyed front/rear rubber floor mats
- Black 4-spoke tilt steering wheel w/anti-theft locking feature
- Warning tones-inc: headlamp-on, key-in-ignition, safety belt, turn signal
- Pwr windows
- Pwr door locks
- Cruise control
- Programmable remote keyless entry system-inc: (2) transmitters, remote panic alarm
- PASSLock theft deterrent system
- Front air conditioning
- Heater ducts under front seats
- ETR AM/FM stereo w/compact disc player, auto tone control-inc: random select, seek/scan speed-sensitive volume, Theftlock, (8) speakers
- Overhead console-inc: (2) storage compartments, garage door opener storage compartment, (4) map reading lamps, dome lamp, electronic compass, outside temperature readout, trip computer
- (5) cup holders
- Cigarette lighter
- Full-length 2-piece foam-backed cloth headliner
- Front/rear passenger assist handles
- Color-keyed padded cloth sun visors w/illuminated mirrors, auxiliary visors & extenders
- Lamps-inc: stepwell, storage compartment, front/middle entry, adjustable reading, rear dome, defeat switch, delayed illum entry
- Color-keyed storage compartment in LH center/rear quarter panels
- Cargo convenience net
- 4-wheel anti-lock braking system (ABS)
- Dual high/low note horn
4.3L (262) MFI V6 VORTEC ENGINE
- Convenience Group
- Power Convenience Group
- Air Conditioning
- Front beverage holders
- Variably intermittent wipers
- Power steering
- Passenger door bin
- Fully automatic headlights
- Front wheel independent suspension
- Front reading lights
- Front anti-roll bar
- Dual front impact airbags
- Driver door bin
- Bumpers: body-color
- AM/FM radio
- ABS brakes
- Voltmeter
- EPA Fuel Economy Est - City (MPG): 15
- EPA Fuel Economy Est - Hwy (MPG): 18
- Cold Cranking Amps @ 0° F (Primary): 600
- Maximum Alternator Capacity (amps): 105
- Maximum Alternator Watts: 1200
- Total Cooling System Capacity (qts): 11.7
- Gross Axle Wt Rating - Front (lbs): 3050
- Gross Axle Wt Rating - Rear (lbs): 3150
- Curb Weight - Front (lbs): 2544
- Curb Weight - Rear (lbs): 2049
- Gross Vehicle Weight Rating Cap (lbs): 6100
- Gross Combined Wt Rating (lbs): 9500
- Dead Weight Hitch - Max Trailer Wt. (lbs): 4900
- Dead Weight Hitch - Max Tongue Wt. (lbs): 470
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 4700
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 470
- Suspension Type - Front: Torsion Bar
- Suspension Type - Rear: Leaf spring
- Spring Capacity - Front (lbs): 3050
- Spring Capacity - Rear (lbs): 3150
- Axle Type - Front: Indep Driving
- Axle Type - Rear: Semi-floating
- Axle Capacity - Front (lbs): 3050
- Axle Capacity - Rear (lbs): 3150
- Axle Ratio (:1) - Front: 3.42
- Axle Ratio (:1) - Rear: 3.42
- Shock Absorber Diameter - Front (mm): 32
- Shock Absorber Diameter - Rear (mm): 32
- Stabilizer Bar Diameter - Front (in): 1.18
- Brake Type: Pwr
- Brake ABS System: 4-wheel
- Disc - Front (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 11.57 x 1.25
- Drum - Rear (Yes or ): Yes
- Rear Drum Diam x Width (in): 9.5 x 2.0
- Front Tire Order Code: QCU
- Rear Tire Order Code: QCU
- Front Tire Size: P215/75R15
- Rear Tire Size: P215/75R15
- Spare Tire Size: Compact
- Front Tire Capacity (lbs): 3166
- Rear Tire Capacity (lbs): 3166
- Spare Tire Capacity (lbs): - TBD -
- Revolutions/Mile @ 45 mph - Front: 753
- Revolutions/Mile @ 45 mph - Rear: 753
- Front Wheel Size (in): 15.0 x 6.5
- Rear Wheel Size (in): 15.0 x 6.5
- Spare Wheel Size (in): Compact
- Front Wheel Material: Chrome
- Rear Wheel Material: Chrome
- Spare Wheel Material: Steel
- Steering Type: Pwr speed sensitive
- Steering Ratio (:1), On Center: 16
- Steering Ratio (:1), At Lock: 13
- Turning Diameter - Curb to Curb (ft): 43.8
- Turning Diameter - Wall to Wall (ft): 43.6
- Fuel Tank Capacity, Approx (gal): 25
- Fuel Tank Location: Fwd of rear axle
- Wheelbase (in): 111.2
- Length, Overall w/rear bumper (in): 189.8
- Width, Max w/o mirrors (in): 77.5
- Height, Overall (in): 75.0
- Overhang, Front (in): 32.5
- Overhang, Rear w/bumper (in): 46.0
- Ground to Top of Load Floor (in): 26.0
- Ground Clearance, Front (in): 6.8
- Ground Clearance, Rear (in): 7.4
- Rear Door Opening Height (in): 42.0
- Rear Door Opening Width (in): 57.2
- Side Door Opening Height (in): 46.8
- Side Door Opening Width (in): 34.5
- Step Up Height - Front (in): 19.5
- Step Up Height - Side (in): 21.5
- Cargo Area Length @ Floor to Console (in): 126.0
- Cargo Area Length @ Floor to Seat 1 (in): 98.6
- Cargo Area Length @ Floor to Seat 2 (in): 61.7
- Cargo Area Length @ Floor to Seat 3 (in): 28.4
- Cargo Area Width @ Beltline (in): - TBD -
- Cargo Box Width @ Wheelhousings (in): 51.6
- Cargo Box (Area) Height (in): 47.2
- Cargo Volume to Seat 1 (ft³): 170.4
- Cargo Volume to Seat 2 (ft³): 104.4
- Cargo Volume to Seat 3 (ft³): 41.3
- Passenger Capacity: 8
- Front Head Room (in): 39.2
- Front Leg Room (in): 41.6
- Front Shoulder Room (in): 64.0
- Front Hip Room (in): 65.0
- Second Head Room (in): 37.9
- Second Leg Room (in): 36.5
- Second Shoulder Room (in): 67.1
- Second Hip Room (in): 50.9
- Third Head Room (in): 38.7
- Third Leg Room (in): 38.5
- Third Shoulder Room (in): 67.1
- Third Hip Room (in): 57.1
- Vehicle Name: Chevrolet Astro Passenger
- Body Style: 111" WB
- Body Code: ZW9
